IKEA LUFTIG - Page 2

Fig. 2.A Fig. 2.B
CHARACTERISTICS
DIMENSIONS
600
500
240
18
210
100
205
490
150
500 / 700 mm
1
Fig. 1
3
4
5
2
2
AA-2037583-3
Ref. Qty. Product Components1
1 1 Hood Body.. etc!
2 1 Chimney
3 1 Reducer Flange, Ø120/150 mm
Ref. Qty. Installation Components
4 2 Hood Body Facing brackets
5 1 Chimney Section Fixing Brackets
2 Clamp ring
Qty. Documentation
1 Instruction Manual
1 Installation Manual
