ENGLISH 14
To remove the door
1. Open the door fully.
2. Lift the catches and push them forwards
as far as they will go (Fig. 1).
Fig. 1
3. Close the door as far as it will go (A), lift
it up (B) and turn it (C) until it is released
(D) (Fig. 2, 3, 4).
A
Fig. 2
B
B
C
Fig. 3
Fig. 4
To ret the door
1. Insert the hinges in their seats.
2. Open the door fully.
3. Lower the two catches.
4. Close the door
Cleaning the glass
1. After removing the door and resting
it on a soft surface with the handle
downwards, simultaneously press the
two retaining clips and remove the
upper edge of the door by pulling it
towards you.
2. Lift and rmly hold the inner glass with
both hands, remove it and place it on
a soft surface before cleaning it. Do the
same operation for the intermediate
glass.
3. To reposition both the intermediate and
the internal glass properly, be sure that
the “R” can be seen in the left corner.
First insert the long side of the glass
indicated by “R” into the support seats,
then lower it into position.
