INSTALLATION INSTRUCTION
WARNING: Turn off the wall switch prior to servicing the unit. To avoid
personal injury, wall switch must be turned off before servicing since
the built-in thermal protection may turn on the circulator
automatically.
1. Mount the control box on the adjacent rafter.
2. Connect the Black and White wire line out from the control box to
the electric lines controlled by a master On / Off switch as shown
below wiring diagram.
