WIRING-CABLE INVENTORY
• COMPLETE LIST OF CABLES IN THE SYSTEM:
• POWER – VAC MAIN POWER SUPPLY CABLE
• PI PWR – POWER TO THE RASPBERRY PI
• LIM SWITCH – SIGNAL BETWEEN PI AND LIMIT SWITCHES
• LIGHT – POWER AND CONTROL OF THE DOME LIGHT
• WATER – POWER AND CONTROL OF THE WATER SYSTEM
• PUMP – SECTION OF WATER CABLE THAT BREAKS AWAY FOR PUMP POWER
• CAM TRG – TRIGGER FOR THE CAMERA
• CAM USB – POWER AND EXTERNAL CONNECTION TO CAMERA
• ETHERNET – COMMUNICATION BETWEEN PI AND MOTOR
• SERIAL – USB TO SERIAL TTL CONNECTION FOR ROUTINE START FROM EXTERNAL RE
