2-seats
2-seats with
center arm
3-seats
3-seats with
center arm
3-seats with
1 center arm
4-seats with
center arm
A
B
“CLICK”
STEP BY STEP ASSEMBLY INSTRUCTIONS ASSEMBLY OF SOFA UNIT
ASSEMBLY OF CENTER ARM
The units are delivered with the back and seat separated .
The back is ready for assembly. Please proceed with thefollowing steps:
Start the assembly with this unit, (from Left to Right).
DIFFERENT UNITS
DISASSEMBLY
If you need to disassembly the unit please start from right to left.
Lift it up and pull forward to unconnect.
Connect more units on the same way
STEP 1
Remove any transportation safeguard arms (if any are attached).
STEP 2
Place the chair/unit on the floor.
STEP 3
Remove the connection protectors on the backs and the flanges/brackets
protectors on the seats.
STEP 5
Use the Velcro tape to fasten the skirt cover onto the lower part of the seat.
STEP 4
Attach the backs by sliding the connectors into the flanges/brackets on the
back part of the seat. Press the back down until you hear “click”. Please ensure
that you don’t tear the skirt cover or that the skirt cover gets squeezed
between the back and the seat.
