Note:
In order to prevent accidents and injuries, please secure the device firmly onto the
wall as illustrated. The wall on which the device is mounted must have a loading
capacity of at least 3 times the weight of the device.
Do not install the device near a heat source, such as an air-conditioner compressor,
air vent of a range hood or air vent of a gas water heater.
As the camera can be rotated horizontally, please pay attention to the safe turning
distance during installation. Do not install the device at a location where its
horizontal movement would be impeded.
The distance between the base plate and the wall should be at least 50mm to allow for
a safety turning distance. Any gap of less than 50mm will result in an obstruction to the
camera's movement.
Top view
50mm
< 50mm
EN-05
