AUDAX TOP ErP and Integrated System

45.3 CIRCULATION PUMP SETTINGS AND CONFIGURATIONS

KEY:

1 - Automatic vent mode operation

2 - Light ring to indicate the operating status

3 - Proportional head operation

4 - Constant head operation

5 - Operating mode selector switch

e kits are supplied with circulating pumps tted with speed

regulator. ese settings are suitable for most systems.

For proper operation one must select the most suitable type of

operation for the system and select a speed between 2 and 7.

- Program constant head (∆P C). The circulator pump

maintains the pressure level (head) constant as the system heat

demand decreases (ow rate reduction). With these settings,

the circulator pump is suitable for all oor systems where all

the circuits must be balanced for the same drop in head. One

can select the operating level from minimum to maximum by

turning the selector switch clockwise in the relative power scale

(refer to the drawing below).

- Program proportional head (∆P V) . is allows the pressure

level (head) to be proportionally reduced as the system heat

demand decreases (ow rate reduction). anks to this func-

tion, the electric power consumption of the circulator pump is

reduced further: the energy (power) used by the pump decreases

according to the pressure level and ow rate. With this setting,

the pump guarantees optimal performance in most heating sys-

tems, proving particularly suitable in single-pipe and two-pipe

installations. Any noise of the water ow in the pipes, valves

and radiators is eliminated by reducing the head. One can select

the operating level from minimum to maximum by turning the

selector switch anticlockwise on the relative power scale (refer

to the drawing below).

45.2 TECHNICAL DATA

Mixed zones 2 kit

2 mixed zones and 1

direct zone kit

Maximum nominal pressure

Maximum operating pressure

Low temperature circuit minimum set point regulation temperature

Low temperature circuit maximum set point regulation temperature

Water content in device

Total head available in non-mixed zone with 1000 l/h ow rate (max)

Total head available in mixed zone (mixing valve closed)

with 1000 l/h ow rate (max.)

Empty device weight

Full device weight

bar

°C

kPa (m H

90*

50/85*

1.5

54.50 (5.50)

21.1

22.6

90*

50/85*

1.9

43 (4.30)

54.50 (5.50)

23.1

25.0

Electrical connection

Maximum input

Installed electric power

Power in stand-by

Electric plant protection

Maximum distance between kit - heat pump or boiler

V/Hz

230/50

0.9

105

9.5

IP20

500

230/50

1.2

150

9.5

IP20

500

* = temperature can only be reached in combination with a boiler.
