impact EX-100A - Page 3

Mount on a stand
(1) Select a stand or support
system of suitable weight
and dimensions to ensure
stable operation of the unit.
Install Reector &
Modeling Lamp
(2) Remove the protective
cap by pressing in and
turning it counter-
clockwise. Pull the cap off
and set aside.
(3) Install the modeling
lamp by screwing it into the
threaded socket.
CAUTION: Do not touch the lamp with your bare hands. Oil residue from your ngers can
cause the surface of the lamp to heat unevenly and explode. Use white cotton gloves or a
clean cloth.
(4) Install the reector where the protective cap was before. Align the two notches on
the reector with the white guidelines on the ash unit, press the reector in and rotate
clockwise until it locks in place. Rotate the outer ring to secure the reector.
Note: Take care when tting or removing reectors or softboxes to not damage the
ashtube assembly. The ashtube is very delicate. Always switch off the unit and
disconnect the power before tting or changing lamps, ashtubes, reectors, or softboxes.
Preparing Your Monolight for Use
Page 18 Page 3
10M 25M 50M 75 M 100M 10Y 25Y 50Y 75Y 100Y
1
3 4
2
Specications
EX-100A
Power Output 100 W/S
Guide Number
1
30
Output Control Range Full power to 1/8 stepless
Recycling Time 1~2 seconds
Flash Duration 1/1000 ~ 1/1500 second
Flash Ready Indicator LED and audible beep
Modeling Lamp 60W (not to exceed 100W)
Triggers Sync cable, slave sensor, test button
Trigger Voltage 4.3V
Built-in Slave Cell Yes
Color Temperature 5800°K ±200°K
Flash Tube Plug-in type, user replaceable
Reector Mount Elinchrom-type
Sync Cable 1/8˝ phono jack
Power Source 110~120V AC, 60Hz
Circuit Protection 6.3A Fuse
Dimensions 9.5 × 7.75 × 5˝ (240 × 198 × 127 mm) – without reector
11.25 × 8.25 × 10.3˝ (285 × 210 × 262 mm) – with reector
Weight 2.6 lb. (1.2 kg)
1
Guide Number is calculated at f/8, 10ft, ISO 100, using the included reector, and is a starting point.
You should perform your own evaluations to determine the results you prefer.
Contents of carton
Carefully remove the monolight from the box. You should have the following:
• monolight with protective cap and ashtube installed
• 60W modeling lamp • 8˝ grid reector • sync cable
• spare fuse • power cable • user manual
You may also have other items, such as a light stand, umbrella, or softbox,
if you purchased the EX-100A as part of a kit.
