8
1. Mount flash shoe directly on
cold shoe adapter found atop
bracket handle and tighten
miniature thumbscrew to
secure
2. Ensure that the flash bulb
extends approximately ½
inch into rectangular center
of speed ring opening;
the desired position can
be achieved by adjusting
thumbscrews B and C
Speed Ring Bracket Instructions
Installing Flash Head On Bracket
