ITEM NO.
Description QTY
ITEM NO.
Description QTY
1 Main Frame 1 29 Resistance Cable 1
2 Poly-v Belt 1 30 Lower Cable of Console 1
3 Left Pedal Bracket ASSY 1 31 Magnet Cord 1
4 Right Pedal Bracket ASSY 1 32 Socket Head Cap Screw M10*80 4
5 Shaft ASSY 1 33 Socket Head Cap Screw M10*50 2
6 Cross Bracket ASSY 2 34 Hex Head Bolt M10*40 2
7 Tightener ASSY 1 35 Hex Head Bolt M10*15 2
8 Bottom Cover 1 36 Hex Head Bolt M8*150 1
9 Plug 1 2 37 Socket Head Cap Screw M8*25 1
10 Plug 2 2 38 Socket Head Cap Screw M6*20 4
11 Little Disk Cover 2 39 Pan Head Phillips Screw M5*15 11
12 Left Front Bottom Cover 1 40 Socket Head Cap Screw M5*15 3
13 Right Front Bottom Cover 1 41
Pan Head Phillips Self-tapping Screw ST4.2*16
16
14 Plug 2 42 Flange Nut M14*1.5 2
15 Wheel 2 43 Nylon Insert Lock Nut M10 4
16 Square Nut 2 44 Nylon Insert Lock Nut M8 1
17 Adjustbale Foot 2 45 Hex Nut M10 4
18 Foot 3 46 Hex Nut M8 1
19 Mid Rear Cover 1 1 47 Hex Nut M5 2
20 Mid Rear Cover 2 1 48 Rivet Nut M5 3
21 Mid Rear Cover 3 1 49 Washer Φ11*Φ20*2 10
22 Tension Spring 1 50 Washer Φ6.6*Φ12*1.6 4
23 Tightening Nut 1 51 Busing 3
25 Wave Washer 4 52 Spring Washer Φ6 4
26 Controller 1 54 External Retaining Ring Φ40 1
27 Brake 1 55 External Retaining Ring Φ25 2
28 Control Cable 1 56 Screw Clip 16
To Next Page
