─ 13 ─

Exploded View and Parts List

Console

ITEM NO.

Description QTY

1 Console Bracket 1

2 Console Top Cover 1

3 Console Bottom Cover 1

4 Console Cabinet 1

5 Circuit Board Frame 1

6 Support Pillar 4

7 PCB 1

8 Handle Pulse PCB 1

9 Wireless Receiver 1

10 Hand Pulse Cable to Console 1

11 Magnet Cord 2

12 Magnet Cord 3

13 Console Overlay 1

14 LOGO 1

15 Button Head Cap Screw M8*20 1

16 Pan Head Phillips Self-tapping Screw ST4.2*16 8

17 Pan Head Phillips Screw M4*10 4

18 Pan Head Phillips Self-tapping Screw ST2.9*9.5 17

19 Washer Φ9*Φ16*1.6 1
