Impulse RE700 User Manual

─ 15 ─
Exploded View and Parts List
ITEM NO.
Description QTY
ITEM NO.
Description QTY
1 Upright Frame 1 8 Socket Head Cap Screw M8*55 4
2 Handle Bracket ASSY 1 9 Socket Head Cap Screw M8*20 4
3 Console 1 10 Pan Head Phillips Screw M5*15 4
4 Water Bottle Holder 1 11 Washer Φ9*Φ16*1.6 8
5 Water Bottle Holder Bracket 1 12 Spring Washer Φ8 4
6 Cover for Water Bottle Holder 1 13 Pan Head Phillips Screw M4*10 2
7 Upper Cable of Console 1
Console ASSY
