Page 23
English
Using the SmartLung for tests in
accordance with the standard
Ventilators and anaesthesia equipment must be verified
in accordance with the following standards:
• EN 60601-2-12Critical care ventilators
(substitute for DIN EN 794-1:2001-02)
• EN 60601-2-13Anaesthetic systems
(replacement for DIN EN 740:1999-02)
• EN 794-3Transport ventilators
• ASTM F1100-90(1997) Critical care ventilators
(US FDA)
These standards determine the following settings for
the SmartLung:
Adult Paediatric Infant,
neonatal
Tidal volume
Vt (mL)
500 300 30
Rate (bpm) 10 20 30
I:E ratio 1:2 1:2 1:2
Test lung
used
SmartLung
20002 L
SmartLung
2000 2 L
SmartLung
Infant 0.5 L
Compliance
(mL/mbar)
50 20 1
Resistance Rp 5 20 50
SmartLung settings for tests in accordance with the standard
