5
Tighten the harness
Pull the shoulder straps upwards to
remove the slack from the lap sections
of the harness then pull the adjuster
strap until the harness is fully
tightened.
Check the harness adjuster
and tighten
each time the child is
placed in the seat.
Loosen the harness
4.4 Adjust and use the harness
The harness is slackened by pressing
the adjuster (under the adjuster cover)
on the front of the seat.Press down the
adjuster as you grip the two shoulder
straps with your another hand. Pull the
shoulder straps towards you to loosen
the harness.
4.3 Usage of buckle
Step1
Step2
Step3
Firstly ,adjust the shoulder straps height ,please proceed as follows:
Step1.
Step2. Slot the two buckle connectors into the slot in the buckle until
you hear click .
Step3. Check the harness is correctly locked by pulling the shoulder
straps upwards.s
To release the harness ,you can press the red button of the buckle
downwards, the two metal sections will be pop up .
“ ”
Put the two metal sections of the buckle connector together.
4.5 Adjust the child seat to different incline positions
The child seat
f the seat upwards, and then pull or push the seat forwards or
backwards. Release the positioning handle in the desired position
and push it until you hear “click”.
Check to make sure the child seat is securely locked in the
desired posit
ion by pulling the positioning handle.
can be adjusted to 3 different positions: position 1,
position 2 and position 3. If installed rearward-facing(group 0+), only
the position 3 can be used. Pull the positioning handle under the front
o
Important:
As is shown in the picture,the
headrest can be adjusted to any
position in order to adapt to the
height of children. as is shown by
the picture, hold the headrest
handle up and down to adjust the
headrest, at the same time the
left and right flank will follow
it.,ensure that the headrest is
located in the position that is
suitable for the child's height.
4.6 Adjust the headrest
6
