3-32 Pre-driving checks and adjustments
SPA2450-A
Automatic anti-glare type
V37-D-121025-544653BF-F3F0-4DF6-B343-B51FC6A721BA
The inside mirror is designed so that it
automatically changes reflection according
to the intensity of the headlights of the
following vehicle.
The anti-glare system will be automatically
turned on when the ignition switch is
pushed to the ON position.
The anti-glare system also operates for the
outside mirrors (if so equipped).
When the anti-glare system is turned on,
the indicator light
*
A
will illuminate and
excessive glare from the headlights of the
vehicle behind you will be reduced.
Push the “*” switch
*
B
to make the inside
mirror operate normally. The indicator light
will turn off. Push the “I” switch
*
C
to turn
the system on.
Do not allow any object to cover the
sensors
*
D
or apply glass cleaner on
them. Doing so will reduce the sensitivity
of the sensor, resulting in improper
operation.
For the HomeLink
®
Universal Transceiver
operation, see “HomeLink
®
Universal
Transceiver” (P.2-61).
OUTSIDE MIRRORS
V37-D-121025-0D342898-430F-456A-9040-9578417F2830
WARNING
Objects viewed in the outside mirror on the
passenger side are closer than they appear.
Be careful when moving to the right. Using
only this mirror could cause an accident. Use
the inside mirror or glance over your
shoulder to properly judge distances to
other objects.
JVP0246X
Adjusting outside mirrors
V37-D-121025-0B4E65C5-2077-45A9-98FC-A8E07B696D9B
The outside mirror control switch is located
on the driver’s armrest.
The outside mirror will operate only when
the ignition switch is in the ACC or ON
position.
Move the switch
*
1
right or left to select
the right or left side mirror, then adjust
using the control switch
*
2
.
Defrosting outside mirrors
V37-D-121025-16A73C41-5F8D-482E-96CB-1F7AF0A050F6
The outside mirrors will be heated when
the rear window defroster switch is oper-
ated.
Condition:
