[ Edit: 2016/ 6/ 21 Model: 2017MY INFINITI Q50(V37) OM17E00V37U0 ]
8-26 Do-it-yourself
SDI1754
5. If the fuse is open
*
A
, replace it with a
new fuse
*
B
. Spare fuses are stored in
the passenger compartment fuse box.
6. If a new fuse also opens, have the
electrical system checked and repaired.
It is recommended you visit an INFINITI
retailer for this service.
Fusible links
V37-D-121025-3E721E86-CD62-4D57-8D17-0637DAF969EF
If any electrical equipment does not
operate and fuses are in good condition,
check the fusible links. If any of these
fusible links are melted, replace only with
genuine INFINITI parts.
JVM0256X
PASSENGER COMPARTMENT
V37-D-121025-D27C130D-9311-435F-AE5F-9BAD54FDFC82
WARNING
Never use a fuse of a higher or lower
amperage rating than that specified on the
fuse box cover. This could damage the
electrical system or electronic control units
or cause a fire.
If any electrical equipment does not
operate, check for an open fuse.
1. Be sure the ignition switch is placed in
the OFF or LOCK position and the
headlight switch is turned to OFF.
2. Open the fuse box lid.
3. Remove the fuse with the fuse puller
*
A
.
4. If the fuse is open, replace it with a new
fuse.
5. If a new fuse also opens, have the
electrical system checked and repaired.
It is recommended you visit an INFINITI
retailer for this service. Spare fuses are
stored in the fuse box.
Condition:
