1-50 Safety — Seats, seat belts and supplemental restraint system
JVR0514X
1. Crash zone sensor
2. Supplemental front air bag modules
(INFINITI Advanced Air Bags)
3. Front seat-mounted side-impact sup-
plemental air bags
4. Occupant classification sensors
(weight sensors)
5. Occupant classification system con-
trol unit
6. Roof-mounted curtain side-impact
and rollover supplemental air bags
7. Roof-mounted curtain side-impact
and rollover supplemental air bag
inflators
8. Pressure sensors in door
9. Air bag Control Unit (ACU)
10. Satellite sensors
11. Seat belts with pretensioners
12. Lap outer pretensioners
INFINITI ADVANCED AIR BAG SYS-
TEM (front seats)
V37-D-121025-F3E1E0CD-4853-4DEE-8BF7-FDF8511DF69C
WARNING
To ensure proper operation of the passen-
ger’s Advanced Air Bag System, observe the
following items.
. Do not allow a passenger in the rear seat
to push or pull on the seatback pocket.
. Do not place heavy loads heavier than
9.1 lbs. (4 kg) on the seatback, head
restraint or in the seatback pocket.
. Make sure that there is nothing pressing
against the rear of the seatback, such as
a child restraint installed in the rear seat
or an object stored on the floor.
. Make sure that there is no object placed
under the front passenger seat.
. Make sure that there is no object placed
between the seat cushion and center
console or between the seat cushion and
