Switching procedure:
Y51D-V-E01-383F1B1E-A2BA-4364-8DED-2DF4A9AEDE13
To switch the hazard indicator and horn
(chime) operation, push the LOCK
*
1
and UNLOCK
*
2
buttons on the Intel-
ligent Key simultaneously for more than 2
seconds.
. When the hazard indicator mode is set,
the hazard indicator flashes 3 times.
. When the hazard indicator and horn
mode is set, the hazard indicator
flashes once and the horn chirps once.
NOS1695
Y51D-V-E01-75D000D4-1871-4E76-9E77-0069D49C3474
JVP0334X
1. Pull the hood lock release handle
*
1
located below the instrument panel;
the hood will then spring up slightly.
2. Pull the lever
*
2
up at the front of the
hood with your fingertips and raise the
hood.
3. When closing the hood, slowly close
the hood down to latch both the right
and left locks. Push the hood down to
lock the hood securely into place.
WARNING
. Make sure the hood is completely closed
and latched before driving. Failure to do
so could cause the hood to fly open and
result in an accident.
. If you see steam or smoke coming from
the engine compartment, to avoid injury
do not open the hood.
Pre-driving checks and adjustments 3-17
HOOD
