[ Edit: 2016/ 8/ 1 Model: 2017MY INFINITI Q70(Y51) OM17E00Y51U0 ]
. To control the air intake automatically,
push and hold either the “
” air
recirculation button or the “
” out-
side air circulation button (whichever
indicator light is illuminated). The
indicator lights (both air recirculation
and outside air circulation buttons) will
flash twice, and then the air intake will
switch to automatic control.
Air flow control:
Y51D-V-E01-EDAABFA3-6A92-43B0-9823-5C7E19A31825
Pushing the “ ” button selects the air
outlet to:
: Air flows from center and side ventilators.
: Air flows from center and side ventilators and
foot outlets.
: Air flows mainly from foot outlets.
: Air flows from defroster and foot outlets.
SAA3002
Models with navigation system
JVH0054M
Models without navigation system
Climate setting screen
Y51D-V-E01-C763BE1E-549A-4B53-8EBF-F71C88BB1338
Climate control settings can be changed on
the screen.
Push the CLIMATE button on the instrument
panel and turn the display to the Climate
mode.
Heating (A/C OFF):
Y51D-V-E01-D7F2049C-B2DA-4C7C-8E30-A63482048C55
The air conditioner does not activate in this
mode. When you need to heat only, use this
mode.
1. Push the CLIMATE button to on.
2. If the “A/C” indicator on the screen
illuminates, select the “A/C” key. (The
“A/C” indicator will turn off.)
3. Push the temperature control button to
set the desired temperature.
. The temperature of the passenger
compartment will be maintained auto-
matically. Air flow distribution and fan
speed are also controlled automati-
cally.
. Do not set the temperature lower than
the outside air temperature. Otherwise
the system may not work properly.
. Not recommended if windows fog up.
When the outside temperature decreases
to approximately −238F (08C), the A/C
Monitor, climate, audio, phone and voice recognition systems 4-59
