ENGINE
Y51D-V-E01-27E56DF3-4A90-4674-8571-79AA70F61975
Model VK56VD VQ37VHR
Type Gasoline, 4-cycle Gasoline, 4-cycle
Cylinder arrangement 8-cylinder, V-slanted at 908 6-cylinder, V-slanted at 608
Bore 6 Stroke in (mm)
3.858 6 3.622
(98.0 6 92.0)
3.760 6 3.385
(95.5 6 86.0)
Displacement cu in (cm
3
) 338.78 (5,552) 225.54 (3,696)
Firing order 1-8-7-3-6-5-4-2 1-2-3-4-5-6
Idle speed rpm No adjustment is necessary.
Ignition timing
(B.T.D.C.)
degree/rpm
Spark plug DILKAR7B11 FXE24HR11
Spark plug gap
(Normal)
in (mm) 0.043 (1.1) 0.043 (1.1)
Camshaft operation Timing chain Timing chain
This spark ignition system complies with the Canadian standard ICES-002.
STI0397B
VK56VD engine
STI0425
VQ37VHR engine
