[ Edit: 2016/ 8/ 1 Model: 2017MY INFINITI Q70(Y51) OM17E00Y51U0 ]
10-16 Technical and consumer information
5. Insert grommets into the hole on the
fascia.
6. Insert a flat-blade screwdriver into the
grommet hole to add 908 turn onto the
part
*
D
.
JVT0339X
Mark the center of the hole
*
E
on both
sides with a felt-tip pen, and then
remove the bracket from the bumper.
Next, drill a 0.39 in (10 mm) diameter
hole on the bumper, approximately
0.20 in (5 mm) below each mark
*
E
.
7. Insert a J-nut into the license plate
bracket before placing the license plate
bracket on the fascia.
8. Install the license plate bracket with
screws.
9. Install the license plate with bolts that
are no longer than 0.55 in (14 mm).
Y51D-V-E01-8B53E02A-80CF-4A3B-9FE9-553395918904
WARNING
.
It is extremely dangerous to
ride in a cargo area inside the
vehicle. In a collision, people
riding in these areas are more
likely to be seriously injured
or killed.
.
Do not allow people to ride in
any area of vehicle that is not
equipped with seats and seat
belts.
.
Be sure everyone in your
vehicle is in a seat and using
a seat belt properly.
TERMS
Y51D-V-E01-78B8C1B5-1A34-4ED5-8630-67E81CC88168
It is important to familiarize yourself
with the following terms before
loading your vehicle:
.
Curb Weight (actual weight of your
vehicle) - vehicle weight includ-
ing: standard and optional equip-
ment, fluids, emergency tools,
VEHICLE LOADING INFORMATION
Condition:
