[ Edit: 2016/ 8/ 1 Model: 2017MY INFINITI Q70(Y51) OM17E00Y51U0 ]
2-12 Instruments and controls
CHECKING LIGHTS
Y51D-V-E01-AAEEDCA0-B409-469E-9994-4005AFDC3266
With all doors closed, apply the parking
brake, fasten the seat belts and place the
ignition switch in the ON position without
starting the engine. The following lights (if
so equipped) will come on:
, or , , , , ,
The following lights (if so equipped) come
on briefly and then go off:
, or , , , , , ,
, ,
If any light does not come on or operates in
a way other than described, it may indicate
a burned-out bulb and/or a system mal-
function. It is recommended you have the
system checked by an INFINITI retailer.
Some indicators and warnings are also
displayed on the vehicle information dis-
play between the speedometer and tach-
ometer. (See “Vehicle information display”
(P.2-21).)
WARNING LIGHTS
Y51D-V-E01-E4342973-71E9-450C-94D9-9EA3FA5505E2
All-Wheel Drive (AWD) warning
light (if so equipped)
Y51D-V-E01-753690F1-01C5-46AF-A68E-329F2E1AAB37
The warning light comes on when the
ignition switch is pushed to ON. It turns off
soon after the engine is started.
If the Intelligent AWD system malfunctions,
or the diameter of the front and the rear
wheels are different, the warning light will
either remain illuminated or blink. (See
“Intelligent All-Wheel Drive (AWD)” (P.5-
126).)
CAUTION
. If the warning light comes on while
driving, there may be a malfunction in
the Intelligent AWD system. Reduce the
vehicle speed and have your vehicle
checked as soon as possible. It is
recommended you visit an INFINITI re-
tailer for this service.
. If the AWD warning light blinks on when
you are driving:
—
blinks rapidly (about twice a sec-
ond):
Pull off the road in a safe area, and
idle the engine. The driving mode will
change to 2WD to prevent the AWD
system from malfunctioning. If the
warning light turns off, you can drive
again.
—
blinks slowly (about once every 2
seconds):
Pull off the road in a safe area, and
idle the engine. Check that all tire
sizes are the same, tire pressure is
correct and tires are not worn.
. If the warning light is still on after the
above operations, have your vehicle
checked as soon as possible. It is
recommended you visit an INFINITI re-
tailer for this service.
or Anti-lock Braking
System (ABS) warning light
Y51D-V-E01-BEE15A76-E254-45AA-8D27-5170CF592A69
When the ignition switch is in the ON
position, the Anti-lock Braking System
(ABS) warning light illuminates and then
turns off. This indicates the ABS is opera-
tional.
If the ABS warning light illuminates while
Condition:
