Reversing near aprojecting object
The predictive course lines
j
Adonot touchthe
object in the display.However,the vehicle may
hit the object if it projects over the actual mov-
ing course.
Reversing behind aprojecting object
The position
j
Cisshown further than the posi-
tion
j
Binthe display.However,the position
j
C
is actually at the same distanceasthe position
j
A.The vehicle mayhit the object when revers-
ingtothe position
j
Aifthe object projects over
the actual moving course.
HOWTOPARK WITH PREDICTIVE
COURSELINES
WARNING
•
If the tyres are replaced with different sizedtyres,
the predictivecourse line maynot be displayed
correctly.
•
On asnow-covered or slipperyroad, there maybe
adifferencebetweenthepredictive courselineand
the actual course line.
•
Thedisplayed lines will appear slightly off to the
rightbecause the rear view cameraisnot installed
in the rear centre of the vehicle.
•
If the batteryisdisconnected or becomes
discharged, the predictivecourselines maybedis-
played incorrectly.Ifthisoccurs, pleaseperform
thefollowingprocedures:
– Turn the steering wheel from locktolock
while the engine is running.
– Drivethe vehicle on astraight road for
more than 5minutes.
•
When thesteering wheel is turned with the igni-
tion switch in the ACCposition, the predictive
course lines maybedisplayed incorrectly.
SAA1923 SAA1980
Displayscreen, heater and air conditioner,and audio system 4-17
