Infinity QX80 - Automatic Climate Controls

16
first drive features
Automatic Climate Controls
1
AUTO BUTTON/TEMPERATURE CONTROL DIAL
Press the AUTO button, and the system will automatically control air flow distribution
and fan speed to achieve and maintain the temperature setting (automatic cooling and/or
dehumidified heating).
Turn the driver’s side temperature control dial to set your desired temperature.
Automatic mode may be used year-round and will work to reach a comfortable temperature
quickly. For example on a very hot day, the system will initially operate at maximum air flow
for rapid cool down.
2
DUAL BUTTON/PASSENGER’S SIDE TEMPERATURE CONTROL DIAL
Press the DUAL button to turn the passenger’s side temperature controls on or off. This will
allow the passenger’s side temperature to be adjusted independently from the driver’s
side control by turning the passenger’s side control.
Turn the passenger’s side temperature control dial left for cooler air or right for warmer air.
3
FAN SPEED CONTROL BUTTONS
Press the fan speed control buttons to manually decrease the fan speed or increase the
fan speed .
4
MODE BUTTON
Press the MODE button to cycle through the following air flow outlets:
Air flows from the center and side vents.
Air flows from the center, side and foot vents.
Air flows mainly from the foot vents.
Air flows from the defroster and foot vents.
5
DEFROSTING/DEFOGGING FRONT AND SIDE WINDOWS
Press the defroster control button to turn the system on. The A/C automatically turns on
when the defroster mode is selected. This feature removes humidity from the air.
Use the temperature control dial
1
to set the desired temperature.
To set the defroster on high, press the fan speed control button to increase the fan speed
to the maximum setting.
6
REAR WINDOW AND OUTSIDE MIRROR DEFROSTER SWITCH
Push the rear window and outside mirror defroster switch to turn the system on or off.
This function automatically turns off after approximately 15 minutes.
1
4
11
10
9
5 6 3 7 8
2
