Infinity Systems • 250 Crossways Park Drive, Woodbury, NY 11797 USA
FAX 516.682.3523 • www.infinitysystems.com
© 2005 Harman International Industries, Incorporated • Part No. INFREFSUBS1/05
SPECIFICATIONS
840w 1040w 1042w 1240w 1242w
Diameter: 8" (200mm) 10" (250mm) 10" (250mm) 12" (300mm) 12" (300mm)
Sensitivity @ 2.83V/1m: 91dB 91dB 91dB 93dB 93dB
Power Handling (RMS): 200W 250W 250W 300W 300W
Power Handling (Peak): 800W 1000W 1000W 1200W 1200W
Frequency Response: 30Hz – 400Hz 25Hz – 400Hz 25Hz – 400Hz 23Hz – 400Hz 23Hz – 400Hz
Impedance: 4 ohms 4 ohms 2 or 8 ohms 4 ohms 2 or 8 ohms
Voice Coil Diameter: 2" (51mm) 2" (51mm) 2" (51mm) 2" (51mm) 2" (51mm)
Mounting Depth: 4-5/16" (110mm) 4-9/16" (116mm) 4-9/16" (116mm) 5-1/16" (129mm) 5-1/16" (129mm)
Overall Diameter: 8-1/4" (210mm) 10-3/8" (264mm) 10-3/8" (264mm) 12-7/16" (316mm) 12-7/16" (316mm)
Cut-Out Diameter: 7-1/16" (179mm) 9-1/8" (232mm) 9-1/8" (232mm) 11-3/16" (284mm) 11-3/16" (284mm)
A valid serial number is required for warranty coverage.
Features, specifications and appearance are subject to change without notice.
Declaration of Conformity
We, Harman Consumer International
2, route de Tours
72500 Chateau-du-Loir
France
declare in own responsibility that the products described
in this owner’s manual are in compliance with technical
standards:
EN 61000-6-3:2001
EN 61000-6-1:2001
Klaus Lebherz
Harman Consumer Group International
Chateau-du-Loir, France 1/05
