Infranor XtrapulsGem User Manual

58
X
trapulsPac – User Guide
Chapter 3 - Referenc
e
Bit
V
alue E
r
ror
Code
Protection Troubleshooting
0 0x00000001 1 Hardware System 2
Error
- Check that the DNC/PLC-amplifier-motor ground
connections and shield answer the Installation manual
requirements.
- Check the application EMC disturbances level.
1 0x00000002 2 24 Volt Error - Check that the logic supply voltage value is within the
specified range.
- Check the logic supply voltage waveform (ripple value,
overvoltage spikes, undervoltage spikes, …)
2 0x00000004 3 Undervolt
(temporized)
- Check that the power supply is actually on.
3 0x00000008 4 Braking system error - Check the presence of either the internal resistor jumper
(XtrapulsPac) or the external resistor (XtrapulsPac and
XtrapulsGem)
- Check that the external resistor is not broken (open circuit)
If the error cannot be reset, the braking system is out of
order (transistor in short-circuit)
4 0x00000010 5 Safety channel 2
Error
- Check the correct STO2 input state with regard to the
STO1 input state
If the STO fault is released, the drive must be turned off in
order to cancel the fault.
5 0x00000020 6 Overvoltage If the failure occurs when starting the amplifier:
- Check the AC supply voltage value.
If the failure occurs during the operation:
- Check the DC bus voltage during the deceleration phases.
- Check the sizing of the braking resistor with regard to the
motor deceleration phases.
6 0x00000040 7 Internal
Communication 2
Error
- Check that the DNC/PLC-amplifier-motor ground
connections and shield answer the Installation manual
requirements.
- Check the application EMC disturbances level.
7 0x00000080 8 IGBT module - Check for no short-circuit in the motor wiring and at the
motor terminals.
- Check for no short-circuit between one motor phase and
the ground.
- Check the amplifier Rated current adjustment with regard
to the allowed value in the amplifier specifications.
- Check that the amplifier max. temperature specifications
are fulfilled.
- Check that the amplifier fan is operating correctly.
8 0x00000100 9 Main Phase Error
9 0x00000200 10 Mains phase loss
10 0x00000400 11 Power Module over-
temperature
- Check the amplifier Rated current adjustment with regard
to the allowed value in the amplifier specifications.
- Check that the amplifier max. temperature specifications
are fulfilled.
- Check that the amplifier fan is operating correctly.
11
12 0x00001000 13 Fan - Available only for some drive models
- Check that the fan blades are not blocked by a foreign body
- Check that the fan rotor is not locked
13
14
15
16 0x00010000 17 Current measurement
offset
- Check that the motor is not driven by the mechanical load
If the error cannot be reset, the amplifier current sensors are
out of order (wrong current measurement)
17 0x00020000 18 Overcurrent - Check the current loop adjustment regarding the motor
inductance.
