Error
Code
Protection Possible Stop on error
selection
Remarks
34 Velocity following error Stop 0 or Stop 2 or Stop 3 Stop 2 selection requires a careful
fault occurrence analysis
35 Position following error Stop 0 or Stop 2 or Stop 3 Stop 2 selection requires a careful
fault occurrence analysis
36 Software position limit Stop 0 or Stop 2 or Stop 3 Stop 2 selection requires a careful
fault occurrence analysis
37 Motor Temperature error Stop 0 or Stop 2 or Stop 3 Stop 2 selection requires a careful
fault occurrence analysis
38 I²t error Stop 0 or Stop 2 or Stop 3 Stop 2 selection requires a careful
fault occurrence analysis
46 Extension Error or
Fieldbus watchdog error
Stop 0 or Stop 2 or Stop 3 Stop 2 selection requires a careful
fault occurrence analysis
49 Fieldbus SYNC cycle error Stop 0 or Stop 2 or Stop 3 Stop 2 selection requires a careful
fault occurrence analysis
50 Fieldbus IP reference
underflow/overflow
Stop 0 or Stop 2 or Stop 3 Stop 2 selection requires a careful
fault occurrence analysis
51 Fieldbus guarding error Stop 0 or Stop 2 or Stop 3 Stop 2 selection requires a careful
fault occurrence analysis
58 CAN Extension Module
communication lost or not found
Stop 0 or Stop 2 or Stop 3 Stop 2 selection requires a careful
fault occurrence analysis
Other Stop 0 only
Important note
: When a Stop 2 or Stop 3 is executed due to a fault occurrence, a second fault occurrence with
Stop 2 or Stop 3 selection cannot be considered.
Sub Index 7
Description AOK mask 1
Data Type Unsigned32
Object Class all
Access rw
PDO Mapping No
Value See 0x3022-1
Default value 0x0000 0004 (UnderVoltage)
Sub Index 8
Description AOK mask 2
Data Type Unsigned32
Object Class all
Access rw
PDO Mapping No
Value See 0x3022-2
Default value 0x0000 0000
These 2 elements (0x3025,7 and 0x3025,8) allow selecting the errors not considered for the AOK signal
deactivation. Errors with the higher criticism regarding fire risk (power stage, braking system) cannot be masked.
