Ingenico iCT250 Quick Reference Guide

To change the paper roll, follow the steps below:
1. Pull up the flap at the top of the US$Direct iCT250 as shown below
2. Pull the flap backwards to open the paper compartment
3. Place the paper roll into the paper compartment. Make sure the end
of the paper is inserted as shown below. Pull a little bit of paper out
towards the top of the terminal Close the paper compartment by
pulling the flap up towards the terminal
4. Close the paper compartment so that a little bit of the paper is
coming out

Ingenico iCT250 Specifications

General

Memory	16 MB RAM, 128 MB Flash
Card Readers	Magnetic stripe, Smart card, Contactless
Operating System	Telium 2
Connectivity	Ethernet
Security	PCI PTS 3.x certified
Printer	Integrated thermal printer
Supported Cards	Visa, Mastercard, American Express, Discover
Display	128x64 pixel LCD, Backlit
Power Supply	External power adapter
