About the Scan Tool
CONTROLS AND INDICATORS
2
CONTROLS AND INDICATORS
Figure 1. Controls and Indicators
See Figure 1 for the locations of items 1 through 14, below.
1.
ER
ASE button - Erases Diagnostic Trouble Codes (DTCs) an
d
"Freeze Fram
e" data from your vehicle's computer, and resets
Monitor status.
2.
SYSTEM MENU button – When pressed, displays the System
Menu.
3. DTC/FF button – Displays the DTC View scre
en and/or scrolls the
LCD dis
play to view DTCs and Freeze Frame data.
4.
LI
NK button - When connected to a vehicle, links the Scan
Tool to the vehicle’s PCM.
14
8
6
5
4
11
12
2
3
9
7
10
13
1
