Step 3 – Pre-Installed Backrest to Base Frame
7
Low Position
Middle Position
High Position
Headrest Adjustment: To adjust the
Headrest (48), unscrew 2 Bolts (40) and 2
Flat Washers (57) and remove it from the
Backrest Support Tube (2). Move the
Headrest (48) to the position desired on
the Backrest Support Tube (2) and screw
2 Bolts (40) and 2 Flat Washers (57) to
secure the Headrest (48) into place.
TIGHTEN ALL NUTS, BOLTS, AND
SCREWS AT THIS TIME
Attach the Pre-Installed Backrest
(2&47&48) to the Connecting Brackets
(11R&11L) using 4 Bolts (29), 4 Flat
Washers (19) and 4 Lock Nuts (21).
Screw the Angle Selector Pin (14) into
the Incline Position 15 hole and tighten.
Before Installation, Please NOTE:
Connecting Brackets (11R&11L) MUST be
pointing downward and the Pre-Installed
Backrest MUST be attached from below
and up into the connecting brackets or the
table will not invert properly.
Connecting Brackets Must Point Downward
When Attaching the Pre-Installed Backrest
