Appendix. Parameter Table
- 316 -
Parameter
No.
Parameter Name Setting Range Default Property Page
Group F7: Keypad Operation and LED Display
F7-00 LED default display check 0, 1 0
☆
-
F7-01 MF.K key function selection 0 to 4 0
★
-
F7-02 STOP/RESET key function 0, 1 1
☆
-
F7-03 LED display running parameters 1 0000 to FFFF 1F
☆
1
1
7
F7-04 LED display running parameters 2 0000 to FFFF 0
☆
1
1
7
F7-05 LED display stop parameters 0000 to FFFF 33
☆
1
4
9
F7-06 Load speed display coefcient 0.0001 to 6.5000 1.0000
☆
-
F7-07 Heatsink temperature of inverter
module
-20°C to 120°C - ● -
F7-09 Accumulative running time 0 to 65535 h - ● -
F7-10 Performance software version - - ● -
F7-11 Function software version - - ● -
F7-12 Number of decimal places for load
speed display
10 to 23 21
☆
-
F7-13 Accumulative power-on time 0 to 65535 h - ● -
F7-14 Accumulative power consumption 0 to 65535 kWh - ● -
Group F8: Auxiliary Functions
F8-00 Jog frequency reference 0.00 Hz to max. frequency 2.00 Hz
☆
1
9
2
F8-01 Jog acceleration time 0.0s to 6500.0s 20.0s
☆
1
9
2
F8-02 Jog deceleration time 0.0s to 6500.0s 20.0s
☆
1
9
2
F8-03 Acceleration time 2 0.0s to 6500.0s Model
dependent
☆
1
2
3
F8-04 Deceleration time 2 0.0s to 6500.0s Model
dependent
☆
1
2
3
F8-05 Acceleration time 3 0.0s to 6500.0s Model
dependent
☆
1
2
3
F8-06 Deceleration time 3 0.0s to 6500.0s Model
dependent
☆
1
2
3
F8-07 Acceleration time 4 0.0s to 6500.0s 0.0s
☆
1
2
3
F8-08 Deceleration time 4 0.0s to 6500.0s 0.0s
☆
1
2
3
F8-09 Frequency jump 1 0.00 Hz to max. frequency 0.00 Hz
☆
1
9
3
F8-10 Frequency jump 2 0.00 Hz to max. frequency 0.00 Hz
☆
1
9
3
F8-11 Frequency jump band 0.00 Hz to max. frequency 0.00 Hz
☆
1
9
3
F8-12 Forward/Reverse run switchover
dead-zone time
0.0s to 3000.0s 0.0s
☆
1
9
4
F8-13 Reverse RUN selection 0, 1 0
☆
1
9
4
F8-14 Running mode when frequency
reference lower than frequency
lower limit
0 to 2 0
☆
1
1
6
F8-15 Droop rate 0.00% to 100.00% 0.00%
☆
1
6
9
F8-16 Accumulative power-on time
threshold
0 to 65000 h 0 h
☆
-
