10
NS-AC10PWH8/ NS-AC12PWH8
www.insigniaproducts.com
Control panel
# Item Description
1 TIMER button Press to set the air conditioner to turn on or off automatically.
2 MODE button Press to cycle the air conditioner through the available modes. Options include COOL,
FAN, DRY, and AUTO.
3 Remote control receiver Receives signals from the remote control. Do not block.
4
(TEMP/TIMER)
buttons
COOLING mode–press to raise or lower the temperature setting. Press at the same time to
change from Fahrenheit to Celsius.
TIMING mode–press to turn the timing on or off.
5 SPEED button Press to select low, medium, or high speed.
6 SWING button Press to turn on the automatic oscillation.
7 Power button Press to turn the air conditioner on or off.
8 LED Display
Tem pe rat ure /Ti me
display
Shows the temperature and time.
NS-AC10PWH8_NS-AC12PWH8_16-0982_MAN_V1_ENG.fm Page 10 Friday, December 9, 2016 3:36 PM
