PART 5 MAINTENANCE & REPAIR PROCEDURES
®
CA-3 & DA-3 Technical Manual 2018 www.insingermachine.com 800-344-4802
Level System
The level control system consists of one level timer
(P/N DE7-35) and one level oat (DE5-60) per tank.
When the system is powered-up, the tank(s) will
begin to ll (assuming no water is in the tanks).
Once the level oat is actuated, the timer begins to
time-out and continues the lling process until the
tank(s) is full.
Should the tank heat energize without water in the
tank troubleshoot the system to nd the problem
CAUTION:
Dirty level oats will cause the tank heat to energize
with no water in the tanks. Level oats MUST be
cleaned daily.
Motor Overloads
All motors used on Insinger Machines are provided
with motor overloads. Motor overloads are adjusted
when the machines are factory tested. Should it be
necessary to adjust the motor overloads in the eld
rst verify the motor current draw for the voltage the
machine is using.
Refer to the Control Panel Layout drawing located in
PART 7 to identify the overload, adjust by turning the
dial to the appropriate AMP draw.
Motor Overload Relay
DE7-35: Liquid Level Timer
