33
®
PART 6 PARTS & ASSEMBLIES
CA-3 & DA-3 Technical Manual 2018 www.insingermachine.com 800-344-4802
1172-27 : CA-3 Final Rinse Piping with Electric Booster
# PART NO. SIZE DESCRIPTION QTY
1 D318F-F1-F1 - Union 1” FIPS x 1” FIPS 1
2 D2944 - Solenoid 1” IPS 1
3 D314F-FC-00 - Nipple Close 1” IPS 6
4 D-2249 - Vacuum Breaker 1” IPS 1
5 D317A-F3-F2 - Adapter 1” C x 1” MIPS 3
6 D207A-B8-16 -
Copper Tubing 1” CTS x
4” Lg.
1
7 D316A-F3-F3 - 90
O
Elbow 1” C 5
8 D318A-F3-F2 - Union 1” C x 1” MIPS 1
9 979-41 A
S/S Vertical Rinse Pipe
Assembly
1
10 D326A-F1 - Locknut 1” IPS 1
11 D314J-ES-16 - Nipple 3/4” IPS x 2” Lg. 1
12 D316E-E3-E1 -
90
O
Elbow 3/4” C x 3/4”
FIPS
1
13 593-24 A
Cross 1” x 3/4” x 3/4” x
1/2” IPS
1
14 D316E-E3-E2 -
90
O
Elbow 3/4” C x 3/4”
MIPS
1
15 D2390SP - Split Jam Nut 1
16 D2390SP-1 - Brass Union 1
17 979-42 A S/S Upper Rinse Pipe 1
18 D318E-E3-E2 -
Union 3/4” C x 3/4”
MIPS
2
19 D207C-L7-73 -
S/S Tubing 7/8” OD x 18
1/4” Lg.
1
20 D207A-B8-156 -
Copper Tubing 1” CTS x
39” Lg.
1
21 D207A-B8-50 -
Copper Tubing 1” CTS x
12 3/8” Lg
1
22 D318A-F3-F3 - Union 1” C 1
# PART NO. SIZE DESCRIPTION QTY
23 D316A-F3-F1 -
90
O
Elbow 1” C x 1”
FIPS
1
24 D207A-B8-66 -
Copper Tubing 1” CTS x
16 1/2” Lg.
1
25 D207A-B8-48 -
Copper Tubing 1” CTS x
12” Lg.
1
26 D329-5 - Drain Cock 1/4” IPS 1
27 D322F-F2-B1 -
Reducer 1” MIPS x 1/4”
FIPS
1
28 D320F-F1F1F1 - Tee 1” IPS 1
29 D322F-E2-41 -
Hex Reducer 3/4” MIPS
x 1/8” FIPS
1
30 D207A-B8-38 -
Copper Tubing 1” CTS x
9 1/2” Lg.
1
31 D207A-B8-64 -
Copper Tubing 1” CTS x
16” Lg.
1
32 D207A-B8-18 -
Copper Tubing 1” CTS x
4 1/2” Lg.
1
33 D322F-E2-B1 -
Reducer 3/4” MIPS x
1/4” FIPS
1
34 D-2497 - Petcock 1/4” IPS 1
35 D320F-F1F1E1 - Tee 1” x 1” x 3/4” IPS 3
36 D328F-E2A - Pipe Plug 3/4” IPS 1
37 925-48 A Support Bracket 1
38 D-2266 -
Pressure Regulator &
Strainer 1” IPS
1
39 D316F-F1-F2 -
90
O
Street Elbow 1”
FIPS x 1” MIPS
1
40 D-2379 - Ball Valve 1” IPS 1
41 SK-1433 -
Pressure Gauge 1/4”
IPS
1
42 D328F-A2A - Pipe Plug 1/8” IPS 1
43 D316A-F3-F2 -
90
O
Street Elbow 1” C X
1” MIPS
1
44 D207A-B8-22 -
Copper Tubing 1” CTS x
5 3/8” Lg.
1
*
*
*
*
**
* Chrome Plated Brass or Bronze
** 24V (unless otherwise noted)
NOTE: Pressure Regulator/Strainer (Item 38) to be
furnished by others unless specied on production card -
use D-2448 “Y” Strainer as standard.
