Inspire BL1 Inspire User Manual

PARTS & HARDWARE LIST
Part # Parts Description Q'ty
Qty Rec'd
Part# Hardware Description Q'ty
Qty Rec'd
1 Front Foot Assembly 1 77
Hex Bolt, M12*160
1
2
Base Frame Assembly
1 79
Hex Bolt, M16*230
4
3 Rear Foot Assembly 1 81
Hex Bolt, M10*70
6
4 Shroud Mount Rod, Lower 2 82
Hex Bolt, M12*90
1
5 Shroud Mount Bracket, Upper 1 83
Hex Bolt, M10*60
3
6 Weight Selector Tube 1 85
Hex Bolt, M10*115
1
7 Slider Assembly 1 86
Hex Bolt, M10*100
5
8 Lower Arm 2 87
Hex Bolt, M10*40
2
9 Upper Arm 2 88
Hex Bolt, M12*100
1
10 Upper Main Frame Assembly 1 89 Hex Bolt, M12*80 1
11 Lower Main Frame Assembly 1 90
Button Head Screw, M6*12
4
13 Top Beam Plate 2 93
Button Head Screw, M6*75
1
14 Press Arm Mount 1 94
Button Head Screw, M6*15
2
16 Press Arm Mount Cover Plate 1 97
Button Head Screw, M10*90
4
17 Lat Bar 1 98
Setscrew, M6*8
2
18 Press Arm Assembly 1 99
Flathead Nut, φ17*23*M6
1
20 Backpad Tilt Frame 1 100 Flat Head Nut, φ17*25.5*M6 2
21 Roller Tube 3 102
Flat Head Screw, M10*15
2
22 Pulley Bracket, Cable Tensioner 1 103
Philips Head Screw, M5*12
1
23 Seat Stem 1 106
Cap Screw, M5*10
1
24 Leg Extension Assembly 1 107
Flat washer, Φ10
24
25 Revolving Straight Bar 1 108
Flat washer, Φ12
8
26 Chain 1 111 Flat washer, Φ40*Φ16.5*2.5 8
37 Pulley Assembly, Φ3 1/2" 11 112 Arc Washer, Φ10 16
38L Shroud, Left 1 116
Lock Nut, M10
19
38R Shroud, Right 1 117
Lock Nut, M12
4
40 Step Bushing, Φ12 ID 8 118
Lock Nut, M16
4
43 Large Plastic Washer 2 120
Allen Wrench, 3mm
1
44 Foam Roller 6 121
Allen Wrench, 4mm
1
45 Endcap, Roller Tube 6 122
4-Way Po Plug Wrench, 5mm
1
47 Pop-Pin Shaft, 140 long 1 123
Allen Wrench, 6mm
1
50 Lat Bar Holder 2
51 Barrel Spacer, 1" Long 6
52 Spacer Tube, 3" long 1
53 Seat Pad 2
65 Foot Plate Assembly 1
68
Cable Assembly
1
69 Cable Ball 2
70 "U" Bracket, Cable End 2
73 Spring Clip 3
74
Adjustable Bumper
4
PAGE 2
