MoRoS GPRS 2.1 PRO Connections
7.2 Terminal Connections on the Top
Figure 3: Connections on the top of the device
Terminal Description Description
1 OUT 1-NC Output 1 normally closed
2 OUT 1 Output 1
3
OUT 1-NO Output 1 normally open
4 OUT 2-NC Output 2 normally closed
5 OUT 2 Output 2
6 OUT 2-NO Output 2 normally open
Table 8: Description of the connections on the top of the device
25
