Integra Duo - Preparing the System: Attaching Holster & Power; Connecting Power Sources

Plug the gray headlight cable into the keyed
connection point on the underside of the
baery holster. Align the indications on
the headlight cable and baery holster
connections; push the connector to snap it
into place.
7
8a
8b
9
6
Clip the baery holster to a comfortable location.
Baery Power Option: Insert and fully seat
the baery into the baery holster. For proper
baery orientation, align the baery so that the
5-pin connector in the holster mates with the 5
slots on the baery.
To power on the LED Surgical Headlight, turn
the intensity knob, located on the underside
of the baery holster, clockwise. Turn the
headlight off by rotating the intensity knob
counter-clockwise.
Direct Power Supply Option: Plug the black
AC power adapter into the baery holster
adjacent to the intensity knob. Align the
indications on the direct power cable and
baery holster connections; push the
connector to snap it into place.
Preparing the System:
Aaching the Baery Holster & Power
16
