Desktop Board D865GLC Specification Update
12
Figure 30 shows the locations of the localized high temperature zones.
OM15925
B
A
D
C
Item Description
A Processor voltage regulator area
B Processor
C Intel
®
82865G GMCH
D Intel
®
82801EB ICH5
Figure 30. Localized High Temperature Zones
Table 45 provides maximum case temperatures for the Desktop Board
D865GBF/D865GLC components that are sensitive to thermal changes. The operating
temperature, current load, or operating frequency could affect case temperatures.
Maximum case temperatures are important when considering proper airflow to cool the
Desktop Board D865GBF/D865GLC.
