Intel
®
Desktop Board D865GLC Specification Update
23
Table 4. Specifications (continued)
Reference
Name
Specification
Title
Version, Revision Date
and Ownership
The information is
available from…
WfM
Wired for Management
Baseline
Version 2.0,
December 18, 1998,
Intel Corporation.
http://www.intel.com/labs/
manage/wfm/wfmspecs.ht
m
3. Change to Description of Table 28, Front Panel Audio Connector
Table 28, Front Panel Audio Connector will change in its entirety as follows:
Table 28. Front Panel Audio Connector
Pin Signal Name Pin Signal Name
1 Mono Mic in (Stereo Mic 1) 2 Ground
3 Mono Mic Bias (Stereo Mic 2) 4 +5 V
5 RIGHT_OUT 6 Right channel return
7 No connect 8 Key
9 LEFT_OUT 10 Left channel return
#
INTEGRATOR’S NOTE
The front panel audio connector is alternately used as a jumper block for routing
audio signals. Refer to Section 2.9.1 on page 83 for more information.
4. Clarification of SMBus Routing
Section 2.8.2.1 will change in its entirety as follows:
2.8.2.1 Expansion Slots
The board has the following expansion slots:
• AGP connector: The AGP connector is keyed for Universal 0.8 V AGP 3.0
cards or 1.5 V AGP 2.0 cards only. Do not install a legacy 3.3 V AGP card.
The AGP connector is not mechanically compatible with legacy 3.3 V AGP
cards.
• PCI rev 2.2 compliant local bus slots (six on the Desktop Board D865GBF,
three on the Desktop Board D865GLC). The SMBus is routed to PCI bus
connector 2 only (ATX expansion slot 6). PCI add-in cards with SMBus
