Intel Desktop Board D865GVHZ Product Guide
28
Installing and Removing Memory
CAUTION
To be fully compliant with all applicable Intel SDRAM memory specification addendums, the board
requires DIMMs that support the Serial Presence Detect (SPD) data structure. You can access the
PC Serial Presence Detect Specification at:
http://www.intel.com/technology/memory/pcsdram/spec/
Desktop Board D865GVHZ has two 184-pin DIMM sockets arranged as Channel A and
Channel B, as shown in Figure 6.
Refer to the “Main Memory” section on page 14 for memory requirements.
OM17023
CHANNEL A
CHANNEL B
Figure 6. Installing a Memory Module
