Intel E39545-004 Service Guide

Workstation Board Features
Intel® Workstation Board S5520SC Service Guide 22
Storage
Controller
Storage
Mode
Description
RAID Types and Levels
Supported
Driver
RAID
Management
Software
RAID
Software
User’s Guide
Compatible
Backplane
IT/IR RAID
4 SAS Ports
Up to 10 SAS or SATA
drives via expander
backplanes
Native SAS pass through
mode without RAID
function.
Entry Hardware RAID.
- RAID 1 (IM mode)
- RAID 10/10E (IME
mode)
- RAID 0 (IS Mode)
SAS MPT
driver (Fully
open-
source
driver)
Broad OS
support.
Intel
®
RAID
Web Console
2
IT/IR RAID
Software
User’s Guide
Optional Intel
®
SAS Entry RAID
module
AXX4SASMOD
SW RAID
4 SAS Ports
Up to 8 SAS or SATA
drives via expander
backplanes
SW RAID 0/1/10 standard
SW RAID 5 with optional
AXXRAKSW5
Microsoft Windows* and
selected Linux* Versions
only
ESRTII
Driver
Intel
®
RAID
Web Console
2
Intel
®
RAID
Software
User’s Guide
AXX6DRV3GR
AXX4DRV3GR
AXX6DRV3GEXP
AXX4DRV3GEXP
