Intel P4000 series User Manual

23
Product Code
MM
UPC
EAN
MOQ
Description
FUP8X35HSBP
916353
00735858222792
5032037033480
1
Hot Swap Backplane spare for 8x3.5" Drive Cage Kit
FUP8X35HSDK for use with P4000 server chassis.
Includes: (1) 3.5” backplane board
FXX8X25HSBP
917973
735858240987
5032037035736
1
Spare 8x2.5" Hot Swap Backplane for use with R2200,
and P4200 Chassis families.
Includes: (1) 8x2.5” backplane board
FXX8X25DPBP
917974
735858240994
5032037035743
1
Spare 8x2.5" Dual Port Hot Swap Backplane for use with
R2200, and P4200 Chassis families.
Includes: (1) 8x2.5” backplane board, dual port
RES2CV240
918934
735858241175
5032037035903
1
Integrated 24-port 6G SAS expander, compatible with
R2200 family and P4000M/P4000L of chassis (only
supported in 2.5” drive 2U or 4U chassis).
Includes 3 screws and bumpers, 4 cables and power
cable.
Recommended to use with two 8x 2.5” Hot Swap
Backplanes (total 16 drives).
RES2CV360
918935
735858241168
5032037035897
1
Integrated 36-port 6G SAS expander, compatible with
R2200 family and P4000M/P4000L family of chassis
(only supported in 2.5” drive 2U or 4U chassis).
Includes 3 screws and bumpers, 6 Mini-SAS cables and
power cable.
Recommended to use with three 8x 2.5” Hot Swap
Backplanes (total 24 drives)
FPWRCABLENA
879287
00735858181129
1
North American Power Cord Spare
AUPLWSFIO
920851
00735858244701
5032037039277
1
Front IO Panel for Intel Workstation P4000CR2 system
with audio, eSATA, and 1394B ports, spare.
AUPLGPUBR
920612
00735858244480
5032037039055
1
Bracket for securing full length double width GPU cards
to fan bulkhead, for use in P4000L/P4000L-WS, includes
1 bracket, four 1100mm GPGPU power cables, screws.
Each GPGPU power cable has one 2x2 pin header to
one 2x3 pin header plus one 2x1 header and one 2x3 pin
header. The 2x3 header plus the 2x1 header can
combine to a standard 2x4 pin header per GPGPU card’s
