BIOS User Interface Intel® Server Board S1200BT TPS
Revision 1.0
Intel order number G13326-003
82
To access this screen from the Main screen, select Server Management > Hardware Monitor
> Realtime Temperature and Voltage Status. To move to another screen, press the <Esc>
key to return to the Hardware Monitor screen, if necessary press the <Esc> key again to
return to the Server Management screen, then select the desired screen.
Server Management
Real time Temperature :
CPU Fan PWM
System Fan PWM
System temperature
Voltage status:
+Vccp
+12V
+3.3V
+5.0V
+1.5V
+1.05V
+3.3V(standby)
Figure 33. Realtime Teperature and Voltage Status Screen (S1200BTS)
6.5.2.18 Boot Options Screen (Tab)
The Boot Options screen displays any bootable media encountered during POST, and allows
the user to configure the desired order in which boot devices are to be tried. The first boot
device in the specified Boot Order which is present and bootable during POST will be used to
boot the system any time the system is rebooted after that.
To access this screen from the Main screen or other top-level Tab screen, press the right or left
arrow keys to traverse the tabs at the top of the Setup screen until the Boot Options screen
is selected.
