Technical Reference
Intel® Entry Server Chassis SC5299-E UP/DP/WS/BRP User Guide 95
650-W Single Power Supply Input Voltages
• 100-127V at 50/60 Hz; 9.63 A
rms
max.
• 200-240V at 50/60 Hz; 4.82 A
rms
max.
650-W Single Power Supply Output Voltages
The following table lists the total amperage available from the power subsystem for each
voltage. Ensure that your loads do not exceed the combined total wattage of 650 Watts.
System Environmental Specifications
Table 7. 650-W Power Supply Output Capability
Voltage
Maximum
Current
+3.3 V 24 A
+5.0 V 30 A
+5 V Standby 3.0 A
-12.0 V 0.3 A
12 V1 16 A
12 V2 16 A
12 V3 16 A
12 V4 16 A
12 V5 18 A
Table 8. System Environmental Specifications
Temperature
Non-operating
Operating
-40 ° to 70 °C.
10 ° to 35 °C; derated 0.5 °C for every 1000 ft (305 m) to a maximum of
10,000 ft.
Humidity
Non-operating 90% relative humidity (non-condensing) at 30 °C.
Shock
Operating
Packaged
2.0 g, 11 msec, 1/2 sine
Operational after an 18" free fall.
Acoustic noise DP, BRP configurations - 5.5 BA LWA idle; 6.0 BA LWA typical operation
WS configuration - 4.8 BA LWA idle; 5.5 BA LWA typical operation
Electrostatic
discharge (ESD)
Tested to 15 kilovolts (kV); no component damage.
