Intel S5520HC Spares Parts List & Configuration Guide

1
9
Picture Product Code MM # UPC MOQ Description
FXX10DVCARBLK 880265 00735858181938 10 Spare hot swap drive carrier with black baffle.
FPWRCABLENA 879287 00735858180740 1 Spare North America Power cable for Intel
®
Server Chassis SC5600, SC5650 family
FXX1000WHEPS 904977 00735858213226 1 Spare 1000W PSU for Intel
®
Server Chassis
SC5650WS
AXX750WPS 901681 00735858207294 1 Spare 750W power supply module for Server
Chassis SC5600LX and SC5600BRP
FXXRIGTFPBRD 901441 00735858208055 1 Spare front panel board for Intel
®
Server
Chassis SC5600
AXXLCPPED 879579
00735858167956 1
Intel® Local Control Panel (LCD) for SC5600
and SC5650 pedestal chassis. Fits in unused
5.25” peripheral bay.
N/A
FRIGTPMKIT 901658 00735858207669 1 Chassis Preventative Maintenance kit for Intel
®
Server Chassis SC5600 family. Includes 1 Front
Panel USB Cable; 1 Serial Cable; 1 Front
92mm Fixed Fan Holder with screws; 1 Front
120mm Fixed Fan Holder with screws; 1 Rear
120mm Fixed Fan Holder with screws; 4 Hot
Swap Fan Wires , 1 Bezel Intrusion Switch, 2
sets / 4 pcs 5.25” tool-less bay rails, 2 sets / 4
pieces of fixed hard drive bay rails, 4 chassis
feet, 1 Air Duct for Intel
®
Server
SC5600BASE/BRP, 1 Air Duct for Intel
®
Server
Chassis SC5600LX
N/A
FPPTPMKIT 901659 00735858207720 1 Chassis Preventative Maintenance Kit for Intel
®
Server Chassis SC5650 family. Includes 2 Hard
Drive Bay Lockers with Screws and Spring, 1
Air Duct, (1) Intrusion Switch Assembly, 1 USB
Cable, 1 Rear 120mm Fixed Fan Holder with
Screws, 1 Fan Holder with Screws for 92mm
fan, 1 Full-length PCI Card Guide, 4 Rivets for
front 120mm Fixed Fan, 1 Adapter Plate with
Screws for Fixed Power Supply, 1 Fixed Power
supply tool-less locker, 4 Chassis Feet, 1 Fixed
HDD Fan Plate, 1 Supporting kit for upgrading
