Server Board Installation and Upgrades 37
Making Connections to the Server Board
OM14422
B C
K
H
J
E
G
D
I
A
T
A
1
0
0
A
F
4
4
A. Auxiliary Power
B. Main Power
C. CPU1 Fan
D. CPU2 Fan
E. Processor Power
F. System Fans 6, 5, 4, 3 (reading
from top to bottom)
G. Front Panel
H. Chassis Intrusion
I. ATA 100 IDE
J. Floppy Disk Drive Connector
K. System Fans 1, 2 (reading
from top to bottom)
Figure 9. Making Connections to the Server Board
