OPERATION INSTRUCTION

Diagnosis Procedures

Refer to the diagnosis codes for the test results.

Single diagnostic

test result

Full diagnostic

test result

Diagnosis MODE

Antenna MODE

Setup mode

SETUP MODE ?

YES NO

1. Press the LEFT arrow key to move cursor to YES and press the OK key to enter SETUP

mode.

+ANTENNA +SATELLITE

+SYSTEM +INSTALLATION

2. Press the OK key to enter ANTENNA menu.

+BLOCK ZONE

+DIAGNOSIS

3. Press the arrow keys to move cursor to DIAGNOSIS and press the OK key to enter it.

DIAGNOSIS COMMUNICATION

FULL TEST READY

4. Press the UP and DOWN arrow keys to select a full diagnostic test or single diagnostic Test

and press the OK key to execute the selected diagnostic test.

DIAGNOSIS FULL TESTING

FULL TEST

- -

5. A full diagnostic is successfully completed.

DIAGNOSIS COMMUNICATION

CODE 101 RESULT : PASSED

6. A single diagnostic test is successfully completed.
