Intellinet NFC30-IRWG Manual

Features
•Excellentimagequalitywith30fpsfull-motion
video in all resolutions
•Progressive-scanimagesensorwithOmniPixel2
technology
•Supportsimageresolutionsupto640x480(VGA)
•Supports54MbpsWireless802.11gwithWEP,
WPA & WPA2 encryption
•Audiosupport,fullduplex,upto8kHz,with
integrated microphone
•VideoaccessthroughanystandardWebbrowser
•Integratedmotiondetectionwithpre-andpost-
alarm image/video buffering
•Event-triggeredFTPande-mailuploadofstill
images and videos
•Externalmicrophoneinputconnector
•Externalspeakeroutputconnector
•Terminalblockforexternalsensorsorexternal
alarm devices
•SupportssimultaneousMPEG4andMotion-JPEG
image compression
•Selectablevideobufferforsmoothervideo
streaming
•Controllableframerate
•SupportsMPEG4videostreamingwithCBR
(constant bit rate) and VBR (variable bit rate) modes
•Forsurveillanceinlowlightornighttimeconditions,
minimum 0 lux (complete darkness)
•EquippedwithanIRlenswith12IRLEDsandone
IR sensor
•IRsensitive,supportsexternalIRIlluminators
•Mobilephonestreaminglivevideothrough3GPP/
ISMA/RTSP
•Mobilephoneliveimagethrough2.5WAP
•WindowsLiveMessengersupport
•Supportsprivacyzoneandtextoverlayfunctionality
•MPEG4+Motion-JPEG+3GPPmobilephone
 streaming,audioand10xdigitalzoom
•SupportsHTTPSencryptionforenhancedsecurity
•SupportsUPnPwithUPnPportforwardingcapability
•Integratede-mail,FTP,DDNSandDHCPclient
•IncludesWindows-basedIPInstallerand
 monitoring/recordingsoftwareforupto16cameras
•Three-YearWarranty
INT-550970-DS-1109-01
Copyright © INTELLINET NETWORK SOLUTIONS
All names of products or services mentioned herein are trademarks or registered trademarks of their respective owners. Distribution and reproduction of this document, and use and disclosure of
the contents herein, are prohibited unless specifically authorized.
For more information on INTELLINET NETWORK SOLUTIONS products,
consult your local dealer or visit
www.intellinet-network.com .
Specifications
NFC30-IRWG Night-Vision Network Camera
STANDARDS
•IEEE802.11b(11MbpsWirelessLAN)
•IEEE802.11g(54MbpsWirelessLAN)
•IEEE802.3(10Base-TEthernet)
•IEEE802.3u(100Base-TXFastEthernet)
GENERAL
•32-bitARM9RISCCPU
•8MByteashmemory
•64MByteSDRAM
•Supportedimageresolutions:640x480,
 320x240and160x120
•Supportedvideocompressionformats:
- Motion-JPEG
 -MPEG4Part2(ISO/IEC14496-2),Prole:SP
•Videoframerate:
 -MotionJPEG:upto15fpsat640x480
 -Upto30fpsat640x480
•Audiosupport:
- Full duplex
 -Bandwidth:G.711PCM,8kHz,64kbit/s
 -Microphone:built-in
 -Audioinput:3.5mm/1.8”microphone
input jack
 -Audiolineoutjack:3.5mm/1.8”
•Uni-andMulticast
•1xalarminput(5V/12VDC)
•1xalarmoutput(max.30W)
•Protocolssupported:TCP/IP,DHCP,PPPoE,
ARP, ICMP, FTP, SMTP, DNS, NTP, UPnP,
RTSP, RTP, HTTP, TCP, UDP, 3GPP/ISMA/
RTSP, Bonjour
•Certications:FCCClassB,RoHS,CE
NETWORK
•LANconnector:RJ45porttoconnectto
 10/100MbpsEthernet
WIRELESS
•Datarates:
 -IEEE802.11b(11Mbps,5.5Mbps,
  2Mbps,1Mbps)
 -IEEE802.11g(54Mbps,48Mbps,
  36Mbps,24Mbps,18Mbps,12Mbps,
  9Mbps,6Mbps)
•Dataencryption:WEP(64-bit&128-bit),
WPA- and WPA2-PSK (with TKIP and AES
authentication)
•Antenna:singledetachabledipoleantenna
with RP-SMA connector, 2 dBi gain
•Operationmodes:Infrastructure,AdHoc
IMAGE SENSOR AND LENS
•Omnivision1/4”progressive-scanCMOS
sensor with OmniPixel2 technology
•VGAresolution(664Hx490V)
•S/Nratio:50dB(max.)
•Pixelsize:6.0µmx6.0µm
•Manualbrightness,contrast,saturation,hue
control
•Minimumillumination:0luxwithIRLEDson
•12IRLEDs,effectiverange10m(30ft.)
•IRwavelength:850nm
•MechanicalIRcutlterwiththreesettings:
On, Off and Auto (with adjustable threshold)
•Focallength4.3mm,angulareldofview
 46˚,objectdistance0.2mtoinnity
•MaximumrelativeapertureF2.0
USERS AND SECURITY
•10useraccounts
•3differentaccesslevels:administrator,
operator and viewer
•Password-protectedaccesstothevideo
streams, or access without password
•HTTPS(SSLv3)
POWER
•Externalpoweradapter:12VDC,1.0A
•Powerconsumption:5.0Watts(maximum)
LEDS
•Power
•Networkconnection
•Cameraoperation
ENVIRONMENTAL
•Dimensions:71(W)x128(L)x42(H)mm
 (5x2.8x1.6in.)
•Weight:0.9kg(2.0lbs.)
•Operatingtemperature:0–50°C(32–122°F)
•Operatinghumidity:20–80%RH,non-
condensing
•Storagetemperature:0–60°C(0–149°F)
SYSTEM REQUIREMENTS
•Pentium41.8GHz(orequivalentAMD)
•64MBRAMvideocard
•Windows2000,XP,Vista,Windows7,
 Linux,MacOSX
•Computerwithnetworkconnection
•Webbrowsersupport:
 -MSInternetExplorer5.0orhigher(ActiveX)
 -Mozilla1.x,MozillaFirefox(Java)
 -NetscapeNavigator6.0orhigher(Java)
- Opera (Java)
- Safari (Java)
- Konqueror (Java)
PACKAGE CONTENTS
•NFC30-IRWGNight-VisionNetworkCamera
•Usermanual
•Cameramountingbracket
•2dBidetachabledipoleantenna
•Externalpoweradapter
•SoftwareCD
