6CD CHANGER PLAYER/1CD PLAYER/STEREO TUNER
9
CD-660/610, TU-610
4. DIGITAL OUT OPTICAL OUTPUT TERMINAL
This is used when outputting digital audio signal recorded in a disc and can transfer digital signal to the AMP
without sound loss through the optical output terminal.
5. L+R MIXING OUTPUT (MONO)
This is used when connecting the XLR L+R Mixing Channel Audio (analog) with the sound input terminal of the
Mixer or the AMP.
6. R-CHANNEL XLR OUTPUT TERMINAL
This is used when connecting the right Channel Audio of the XLR (analog) with the sound input terminal of the
Mixer or the AMP.
7. L-CHANNEL XLR OUTPUT TERMINAL
This is used when connecting the left Channel Audio of the XLR (analog) with the sound input terminal of the
Mixer or the AMP.
8. RCA OUTPUT TERMINAL
This is used when connecting the 2 Channel Audios (analog) with the sound input terminal of the Mixer or the AMP.
9. GND TERMINAL
This is a grounding connection terminal for safety when storm exists.
10. ANTENNA TERMINAL
FM terminal: Uses built-in antenna only for FM and can connect 75Ω coaxial cables in case of feeling noise.
AM terminal: Uses built-in antenna only for AM and can connect lead antenna or outdoor antenna in case of
feeling noise.
