DIGITAL POWER AMPLIFIER
6
DPA-300S/600S/900S/1200S, DPA-300SO/600SO/900SO/1200SO
8. OUTPUT VOLTAGE SELECTOR
T
his two-position switch is used to select a output voltage (100V or 70V).
9. PGM INPUT CONNECTOR
Balanced 3-pin terminal block connector accept the source input.
